UW- value ≤ 0.9
Kömmerling Xtrem 76 AD is the evolution of the popular 76 series, developed specifically for regions with high solar activity, such as Spain. The PVC composition includes special S-class stabilizers that prevent profile deformation under extreme heat. The system with 76 mm installation depth provides excellent insulation, keeping the inside of your home cool and reducing air conditioning costs.
Thin frames let in more Mediterranean light, and two circuits of high-quality sealing reliably protect against dust and noise. This is the "gold standard" for those seeking German quality adapted for the Spanish sun.
Article number
200.100.002
Technical Specifications
Details
A universal option for the Spanish sun. The special profile composition is not afraid of heat and does not yellow over time. This is the "golden mean" for those who need reliable German windows without overpaying for extra options.
Energy efficiency
A
Material
PVC (Xtrem)
Profile depth
76 mm
Insulation
5 chambers
Glazing unit
up to 50 mm
Thermal protection (Uw)
≤ 1.1 W/(m²·K)
Sound insulation
≈ 44 Rw(dB)
System structural parameters:
- Xtrem technology: Special S-class PVC formula with increased titanium dioxide concentration for protection against harsh Spanish solar radiation.
- Installation depth: 76 mm.
- Profile construction: 5-chamber system providing optimal balance between weight and thermal insulation.
- Sealing system: Double-circuit (AD) with co-extruded seals resistant to drying in the sun.
- Design: Straight, clean profile lines matching modern Spanish architecture.
- Reinforcement: Enhanced steel section to compensate for thermal expansion when installing dark laminated windows.
Glazing and infill options:
- Maximum infill thickness: up to 50 mm.
- Optimal package: Allows installation of powerful double-chamber packages with selective glass (Guardian Sun) for overheating protection.
Maximum construction dimensions:
- Maximum sash height: up to 2400 mm (white) / 2300 mm (colored).
- Maximum sash width: up to 1500 mm.
Certified characteristics:
- Profile thermal insulation (Uf): 1.0 W/m²K.
- Water tightness: up to E2250.
- Air permeability: Class 4.
- Sound insulation: up to 46 dB.
- Wind resistance: up to C5.
- Burglar resistance: RC2.
Documentation
Technical Specifications
PDF. 534Kb
Xtrem technology for hot climates
Protection from aggressive sun
More natural light in your home
Maximum light transmission
Reinforced steel reinforcement
Structural stability
Kömmerling Xtrem 76 AD
A universal option for the Spanish sun. The special profile composition is not afraid of heat and does not yellow over time. This is the "golden mean" for those who need reliable German windows without overpaying for extra options.
Calculate Cost
Estimated manufacturing time 3-6 weeks.
Eligible for NextGen Subsidy -80%
Get up to €3,000 back on this window
Available Services
Free measurement and design More details
Delivery to installation site More details
Installation by our specialists More details
Buy by Phone
Call us Monday to Saturday, except holidays, from 8:00 AM to 10:00 PM. Sundays and holidays from 10:00 AM to 8:00 PM. Call
More Ideas and Inspiration
These are some examples of our work with Kömmerling Xtrem 76 AD profile. All this inspiration is for you and only for you.
* - Photos provided by our partners and may differ from actual products.
We are working on keeping data up-to-date. Contact us if you need fresh materials.
We are working on keeping data up-to-date. Contact us if you need fresh materials.
Financing Options
Enjoy your purchase now and pay for it in installments using our financing services.
More detailsDon't Forget to Add
Additional elements and accessories that will make your home even more comfortable
Mosquito Nets
Protect your home from insects, dust, and pollen, allowing you to enjoy fresh air even in the middle of summer.
Handles and Locking Elements
Quality hardware ensures ease of use and security for your windows and doors.
Lamination
Colorful home facades and the desire to decorate your home leads to growing demand for laminated windows every year.
Decorative Elements
Decorative strips and bars allow you to give your windows an individual style, emphasizing the architectural features of your home.
Compare with Similar Profiles
Alternative solutions from other manufacturers
UW- value ≤ 1.1
Kömmerling EuroFutur Elegance
A classic choice for quick and cost-effective renovations. Ideal for replacing old windows in apartments: easily fits standard openings and looks cozy in interiors thanks to its soft, rounded lines.
Energy efficiency
B / A
Material
PVC (Greenline)
Profile depth
70 mm
Insulation
5 chambers
Glazing unit
up to 39 mm
Thermal protection (Uw)
≤ 1.3 W/(m²·K)
Sound insulation
≈ 40 Rw(dB)
UW- value ≤ 0.8
Kömmerling Xtrem 76 MD
The best solution for seaside homes. The third sealing circuit acts as a barrier: it keeps out salt dust and moisture, protecting mechanisms from corrosion, and much better dampens street noise.
Energy efficiency
A+
Material
PVC (Xtrem)
Profile depth
76 mm
Insulation
6 chambers / 3 circuits
Glazing unit
up to 50 mm
Thermal protection (Uw)
≤ 1.0 W/(m²·K)
Sound insulation
≈ 47 Rw(dB)
UW- value ≤ 0.87
Kömmerling 76 MD Zero
A designer "hidden sash" system. From the outside, the window looks like solid glass without extra frames. It lets maximum light into your home and is ideal for modern minimalist villas.
Energy efficiency
A+
Material
PVC (Hidden sash)
Profile depth
76 mm
Insulation
6 chambers / 3 circuits
Glazing unit
up to 50 mm
Thermal protection (Uw)
≤ 0.87 W/(m²·K)
Sound insulation
≈ 45 Rw(dB)
UW- value 1.3
Rehau Euro-design 70
Classic 5-chamber system with 70 mm depth, reliable and economical for standard construction. HDF surface.
Energy rating
A
Profile chambers
5 chambers
Profile depth
70mm
Profile height
108mm
Glass unit
up to 40mm
Thermal protection
Uw ≤ 1.3 W/(m²·K)
Sound insulation
≈43 Rw(dB)
UW- value 0.94
Rehau Synego
7-chamber system with 80 mm depth, providing high thermal and sound insulation for comfortable living. HDF.
Energy rating
A++
Profile chambers
7 chambers
Profile depth
80mm
Profile height
117mm
Glass unit
up to 51mm
Thermal protection
Uw ≤ 0.94 W/(m²·K)
Sound insulation
≈46 Rw(dB)
UW- value 1.2
Rehau Brillant-Design 70
Premium 70 mm system with elegant design, smooth HDF surface and good thermal insulation properties. HDF
Energy rating
A
Profile chambers
5 chambers
Profile depth
70mm
Profile height
116mm
Glass unit
up to 42mm
Thermal protection
Uw ≤ 1.2 W/(m²·K)
Sound insulation
≈43 Rw(dB)
Available in Your Region
We work throughout Spain
Leave a Review
Customer Reviews
Find out what people are saying about it
0.0
Average rating
0 reviews
5 ★
0
4 ★
0
3 ★
0
2 ★
0
1 ★
0
No reviews yet. Be the first!
FAQs
Frequently Asked Questions about Kömmerling Xtrem 76 AD
What exactly does the Xtrem marking mean for the Spanish climate?
The Xtrem marking confirms that the profile has been certified for use in regions with extremely high solar radiation levels (class S according to international standards). Special modifiers are added to the PVC composition to prevent yellowing and brittleness of plastic under intense ultraviolet radiation typical of the Costa Blanca and southern Spain.
How does the 76 AD system differ from standard 70 mm profiles?
The increased depth to 76 mm allows the use of wider and warmer glazing units up to 50 mm. In addition, the 5-chamber structure of 76 AD is designed according to the principle of optimal isotherm distribution, making the window 25% more efficient than old systems while maintaining a thin and elegant profile appearance.
How does this window handle urban noise?
Kömmerling Xtrem 76 AD combined with a quality acoustic glazing unit provides noise reduction up to 47 dB. This means that busy street sounds or passing traffic will be perceived indoors as barely audible whisper, creating an ideal atmosphere for rest or work.
Why do they say it becomes brighter in the house with these windows?
Kömmerling engineers minimized the visible width of the frame-sash combination to 116 mm. This allows increasing the transparent part (glazing unit) area. You get 5-10% more natural sunlight in the room compared to standard wide PVC profiles, which visually expands the space.
How airtight is the system in strong wind and rain?
The 76 AD system is equipped with two circuits of high-quality EPDM seal that maintains elasticity for decades. The window has the highest Class 4 air permeability and Class 9A water tightness, guaranteeing no drafts or leaks even during severe coastal storms.
What color options are available for this model?
Over 50 lamination options are available for Xtrem 76 AD: from classic wood textures to modern metallic shades. Thanks to UV-resistant film, the color does not fade in the sun, and proCoverTec technology allows ordering windows with a unique matte surface that is pleasant to touch and resistant to dirt.
